Pulse’s new range of 1000BASE-T Ethernet Connector Modules are designed to meet the latest trend in Ethernet connectivity. The demand for
Energy Efficiency and "greener" devices has created new Voltage driven PHYs compliant to IEEE802.3az for Energy Efficient Ethernet (EEE).
These new Pulse products operate with the leading voltage driven silicon and PHYs from all the major manufacturers.
Building on Pulse’s latest “JXD” range of compact ICM’s, the new series features two schematic options for easy PCB layout, LED and EMI
Applications:
Industrial Automation, Process or Remote Control and
Monitoring, Campus, Factory or Rugged Communication
Networks, Routers, Switches for SMB and SoHO markets
Features and Benefits:
•Designed to meet IEEE802.3ab (1000BASE-T) standards
•-40C to +85C operating temperature
•Suitable for CAT 3, CAT 5 UTP or higher
•Easy PCB layout due to Dual Schematic options
•UL File Listing E216177
•Compact form factor optimizing board space
•Supports all major PHY manufactures
JXD1 JXD0
JXD2 JXD0-2 JXD1-2 JXD0-4
www.Networking.PulseElectronics.com | © Copyright 2017, Pulse Electronics All rights reserved.
Featured Products:
JXD0-00XXNL
Side Entry, 1x1, Tab Down
JXD1-00XXNL
Side Entry, 1x1, Tab Up
JXD0-20XXNL
Side Entry, 1x2, Tab
-Down
JXD1-20XXNL
Side Entry, 1x2, Tab
-Up
JXD0-40XXNL
Side Entry, 1x4, Tab
-Down
1Gigabit Connector modules for Energy Efficient Ethernet
Pulse introduces a series of 1x1, 1x2 and 1x4 1000BASE-T Ethernet Connector Modules for the IEEE 802.3az
Standard for Energy Efficient Ethernet (EEE)
@Pulse
Electronics
NETWORKING
Taerown RJ4‘o Taerp RJ4b
KEV : , 1m 4 ,,
Omrmcd PHY
N. J JXDI UCZGM
OHM cd PW
Buy Now
Easy PCB Layout:
Each part has been designed for easy PCB layout no matter what orientation of PHY or Tab location is desired, as all complex routing is made
inside the Pulsejacks, reducing EMI and leading for a simple PCB layout.
www.Networking.PulseElectronics.com | © Copyright 2017, Pulse Electronics All rights reserved.
Industrial 1000BASE-T Ethernet Connector Modules
PART No. TAB
LOCATITON No. Ports EMI TABS PHY Style LED Left/Right
(pin style)
JXD0-0015NL DOWN 1x1 YES anti-c/w Green/Yellow (in-Line)
JXD0-0019NL DOWN 1x1 NO anti-c/w Green/Yellow (in-Line)
JXD0-0025NL DOWN 1x1 YES clock/w Green/Yellow (in-Line)
JXD0-0029NL DOWN 1x1 NO clock/w Green/Yellow (in-Line)
JXD1-0015NL UP 1x1 YES anti-c/w Yellow/Green (sides)
JXD1-0019NL UP 1x1 NO anti-c/w Yellow/Green (sides)
JXD1-0025NL UP 1x1 YES clock/w Yellow/Green (sides)
JXD1-0026NL UP 1x1 NO clock/w Yellow/Green (sides)
JXD0-2015NL DOWN 1x2 YES anti-c/w Green/Yellow (in-front)
JXD0-2019NL DOWN 1x2 NO anti-c/w Green/Yellow (in-front)
JXD1-2015NL UP 1x2 YES anti-c/w Yellow/Green (in-front)
JXD1-2016NL UP 1x2 NO clock/w Yellow/Green (in-front)
JXD0-4015NL DOWN 1x4 YES anti-c/w Green/Yellow (in-front)
JXD2-0015NL TOP ENTRY 1x1 NO ~ Yellow/Green (top)
